8ch 5-in-1 Dvr 5mp 4-in-1 9-22mm Varifocal Zoom Security Camera System

Description

High End 8CH 5-in-1 DVR With 5MP 8pcs 4-in-1 9-22mm long Distance Varifocal Zoom Lens Camera System

DVR Feature

• 8 CH TVI / CVI / AHD video input
• Recording: TVI / AHD : 5MP 10fps; 4MP/3MP 15fps, 2MP 30fps
• 4 x IPC In (Up To 12)
• Playback: 8CH simultaneously playback; HDMI 1080P output
• Backup: USB, IE, CMS; support multi-file, file cutting when backup
• Pentaplex: live, record, playback, backup and remote operation
• Titanium OS
• DHCP, DDNS, PPPoE Network protocol, IE browse and CMS supported
• Dual stream technology; Multi-user online simultaneously
• Support PTZ preset and auto cruise, up to 128 presets and 8 cruises
• Cell phone: iPhone, Android
• Complete SDK function, easy to integrate with other applications
• Max HDD: 1 x HDD

 Specification

Video & Audio

Video Input

8 x BNC (HD TVI / HD AHD / HD CVI / 960H)

IPC Input

4 x IP Camera (Up To 12)

Video Output

HDMI/VGA/CVBS(SPOT)

Audio In

1 x RCA

Audio Out

1 x RCA

Playback

Playback

8CH

Search Mode

Time, Motion, Single, or Multi-Channel

Recording

Recording Resolution

5MP, 4MP, 3MP,1080P, 720P, WD1

Frame Rate (fps)

5MP: 10fps (PAL / NTSC), 4MP / 3MP: 12 fps (PAL) / 15 fps (NTSC), 1080P/720P/WD1: 25 fps (PAL) / 30 fps (NTSC)

Frame Rate (IPC)

25fps (PAL) / 30fps ( NTSC ), 4MP / 3MP / 1080P / 960P / 720P

Bit Rate

768Kbps ~ 8Mbps (Per CH)

Record Mode

Manual, timer, motion, sensor

Alarm

Alarm In

N/A

Alarm Out

N/A

Trigger Events

Record, snap, preset, e-mail, etc.

Mode

Manual, sensor, motion, exception

Network

Ethernet

RJ45 10 / 100Mbps × 1

Protocol

TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP

User Access

10 Users online, dual stream

Storage

Internal HDD

SATA × 1, max 8T HDD

External HDD

N/A

Auxiliary Interface

RS485

RS485 × 1, connect to PTZ or keyboard

USB

USB 2.0 × 1 ( front ), USB 3.0 × 1 ( rear )

General

Power Supply

DC 12V

Power Consumption

≤ 10W ( without HDD )

Working Environment

14℉ ~ 122℉ (-10℃ ~ 50℃), 10%~90% (Humidity)

Dimensions

11.8" x 9.8" x 2" (300 × 248 × 52mm) ( W × D × H )

Bullet Camera Feature

• 4-In-1 (AHD, HD-TVI, HD-CVI, 960H)
• 1/2.5" Megapixels CMOS
• 9-22mm long Distance Varifocal Zoom Lens
• 36 IR, 0Lux
• IR Distance: 196ft
• 12V DC, IP66, IK10
• OSD Menu, Can Switch to Analog Mode
• CoC Compatible (Control Over Coax)

 Camera Specifications

Image Sensor

1/2.5" Megapixels CMOS

Effective Pixels

2592(H) × 1944(V)

Electronic Shutter

PAL:1/50s~1/100,000s, NTSC:1/60s~1/100,000s

Mini. Illumination

0.01Lux  F1.2, 0Lux (IR on)

S/N Ratio

≤52dB (AGC Off)

Video Output

Composite Signal (1.0Vp-p, 75Ω), Compatible with AHD, HD-TVI, HD-CVI, 960H

Video Frame Rate

NTSC: 5MP 20FPS

Camera Features

AGC

Automatic / manual

IR LEDs

36 IR

IR LEDs Distance

196ft

Day / Night

Auto / Color / BW / EXT

Noise Reduction

2D

BLC

Automatic / manual

White Balance

Auto (Range 2500～8500K)/ Manual

WDR

DWDR

OSD Menu

via Coaxial Cable (CoC), Compatible with Analog Mode

Display

Resolution

5MP

Lens

Angle of View

Horizontal Field view:80°

Focal Lens

9-22mm Varifocal Lens

Recording

Encode

CBR

General

Power Supply

DC 12V ± 10%

Power Consumption

85mA (IR Off), 250mA (IR On)

Working Environment

14℉ ~ 113℉ (- 10℃～+45℃)

Protection

IP66, IK10

Dimensions

4.1" (R) x 3.15" (H) (105mm x 80mm)

Weight

0.86kg

Package includes

• HD 8Channel 5-in-1 DVR
• 2TB CCTV hard drive
• 8pcs 5MP 4-in-1 Camera
• 4x 25feet Cable
• 4x 50feet Cable
• Power Adapter & 1 in 8 Power Splitter
• One Year Warranty
